| Power supply | 50/60Hz 220V single-phase |
| Processing length | 30mm (total length) -99999mm |
| Wire processing material range | Precision AWG#20-AWG32# (2-wire feeding) |
| Large wire AWG#8-AWG20# (4-wire feed wire) | |
| Processable range of terminals | The spacing ranges from 0.8 to 3.96 mm, and custom-made partial closed continuous insertion terminals as well as single- terminal components are available. |
| Capacity | 2800-3200PCS/H (13-200mm length when) Actual efficiency is subject to wire measurement. |
| Peeling length | End A: 0-6mm; End B: 0- 10mm |
| Cutting precision | ± ½0.2%*L+1) mm |
| Air pressure | 0.5-0.7Mpa (5-7KG/m³) |
| External dimen- sions | 1400*800* 1500mm matching rack size wire 920*560* 1300mm |
| Weight | Approximately 450KG±15KG with the accompanying wire release frame,weight approximately 800KGS. |
